1. Specify the type of callout head and the radius of the callout bubble.
2. In a project, click on the Manage tab, in the Settings panel find Additional Settings (the big spanner), drop down and select Callout Tags.
3. In the Type Properties dialogue, specify the type of Callout Head to use.

.

Similarly, how do you edit a callout in Revit?

Help

1. In the parent view, select the callout bubble.
2. On the Properties palette, click (Edit Type).
3. In the Type Properties dialog, for Callout Tag, select the callout tag to use. If the desired callout tag is not listed, you can create a new callout tag.
4. Click OK to save your changes.

Also, how do you name a callout in Revit? Help

1. Open the view in which you want to add a callout to a drafting view.
2. Click View tab Create panel (Callout).
3. On the Reference panel, select Reference Other View.
4. Select a reference view name from the drop-down list.

Then, how do you tag a callout in Revit?

Create a Callout Tag

1. In a project, click Manage tab Settings panel Additional Settings drop-down (Callout Tags).
2. In the Type Properties dialog, for Callout Head, specify the type of callout head to use.
3. For Corner Radius, specify the radius of the corners for the callout bubble.
4. Click OK.

What is a callout in Revit?

In Revit Architecture, you can create reference callouts, detail callouts, and view callouts. When you add a detail callout to a view, Revit Architecture creates a detail view. (See Detail Views.) The detail view displays in the Project Browser under Views (all) Detail Views.

Related Question Answers

How do I add details in Revit?

1. Do one of the following to activate the view creation tool:
2. From the Type Selector, select Detail View: Detail.
3. On the Options Bar, select an appropriate detail scale.
4. To reference another detail or drafting view, on the Reference panel, select Reference Other View, and select a view from the drop-down list.

How do you make a callout bubble in Autocad?

1. On the Tool Palettes, click (Properties), and click Document.
2. Click the Callouts palette.
3. Select the callout tool most similar to the tool you want to create.
4. Right-click, and click Copy.
5. Select the copied tool, right-click, and click Properties.
6. Rename the tool as desired.

How do you create a view reference in Revit?

1. Open the view to which you want to add a reference.
2. Click Annotate tab Tag panel View Reference.
3. Optionally, on the View Reference panel, under View Type, select the type of view to display for the Target View list.
4. On the View Reference panel, select the Target View (the view you wish to reference).
